NH1GG69V125P 1250V 69A SiC MOSFET Module Low Rds(on) 11mΩ Fast Switching High Frequency High Temp 175°C Low Loss Industrial Grade For Solar and Industrial Drives
Features
Applications
Description
The NH1GG69V125P is a high-voltage Silicon Carbide (SiC) MOSFET module designed for demanding industrial power conversion applications. It delivers a high-performance 1250V voltage rating with a continuous current capacity of 69A. Utilizing the superior properties of SiC technology, the module features an extremely low on-state resistance (Rds(on)) of 11mΩ, which drastically reduces conduction losses. It also enables exceptionally fast switching speeds with minimal associated losses, allowing for high-frequency operation that leads to increased power density and smaller passive components. The module is engineered for industrial-grade robustness, supporting high junction temperatures for reliable operation in harsh environments.
INFORMATION
| Item number | P219801 |
| Catalogue No | NH1GG69V125P-2 |
| Description | DIN NH Standard fuse-link gG Size NH1 690VAC 125A live tags Striker Body width 44.60 mm |
| EAN/UPC Code | 8430399012346 |
| Rated voltage AC IEC | 690 V |
| Ampere Rating | 125 A |
| ROHS Compliant | Yes |
| AC or DC | AC |
| Speed/Characteristic | gG |
| Fuse Size | NH1 |
| Mounting | Clip |
| AC Max I.R./Breaking Capacity: I1 | 80 kA |
| Design Details | live tags |
| Indication System | Yes |
| Indication System Type | Striker |
| Connection/Terminal Material | Silver-Plated Copper |
| Connection/Terminal Type | Plain Blades |
| Product Width | 44.6 mm |
| Product Length | 135 mm |
| Product Height | 64 mm |
| Sell Pack Quantity | 3 EA |
| Sell Pack Weight | 1.041 kg |
| Sell Pack Width | 132 mm |
| Sell Pack Length | 138 mm |
| Sell Pack Height | 40 mm |
| Product group | Low Voltage IEC Fuses |
| Body/Insulating Material | Ceramic |
| Product Weight | 0.347 kg |
| Power Dissipation at Rated Current Value | 9.6 W |
